Square Nuts for ANSI Inch Series

  • Carbon Steel

  • Square Head

  • Common Bolt

Availability:
Square Nuts for ANSI Inch Series
Square Nuts for ANSI Inch Series
Square Nuts for ANSI Inch Series
Square Nuts for ANSI Inch Series
Square Nuts for ANSI Inch Series
Square Nuts for ANSI Inch Series

Product Description

Square Nuts For ANSI Inch Series
Product Parameters


d
1/4 5/16 3/8 7/16 1/2 5/8 3/4 7/8 1 1-1/8 1-1/4 1-3/8 1-1/2
d
PP UNC
UNF
8-UN
s
e
m
0.2500 0.3125 0.3750 0.4375 0.5000 0.6250 0.7500 0.8750 1.0000 1.1250 1.2500 1.3750 1.5000
20 18 16 14 13 11 10 9 8 7 7 6 6
28 24 24 20 20 18 16 14 12 12 12 12 12
- - - - - - - - - 8 8 8 8
0.425 0.547 0.606 0.728 0.788 0.969 1.088 1.269 1.450 1.631 1.812 1.994 2.175
0.438 0.562 0.625 0.750 0.812 1.000 1.125 1.312 1.500 1.688 1.875 2.062 2.250
0.554 0.721 0.802 0.970 1.052 1.300 1.464 1.712 1.961 2.209 2.458 2.708 2.956
0.619 0.795 0.884 1.061 1.149 1.414 1.591 1.856 2.121 2.386 2.652 2.917 3.182
0.203 0.249 0.310 0.356 0.418 0.525 0.632 0.740 0.847 0.970 1.062 1.169 1.276
0.235 0.283 0.346 0.394 0.458 0.569 0.680 0.792 0.903 1.030 1.126 1.237 1.348
* Good service / Reasonable price / Best quality .
* Customized products are also welcomed .
*Material:Carbon steel/stainless steel


All finishes comply with RoHS compliant
*** Standard nuts or speical items according to drawing accetable.
*** Small box packing and customized label availabel.
*** Pallets no need to pay price difference.
*** Quick reply and price can be quoted within 1 working day.
*** Free samples can be supplied for approval.
*** Lead time from 30-50 days depends on orders.
Company Profile


NINGBO MIANXUAN FASTENERS CO.,LTD. is a professional exporter specialized in fasteners products and located in Ningbo ,a beautiful city bordering on the East China Sea . The main products include various kinds of Bolts,Screws ,Nuts,Thread Rods,Stamping Parts that conform to the DIN,ISO, ANSI ,ASME ,BSW, J IS standards. The company also customizes non-standard items according to customer's requirements and specifications.

After a continuous creation and developmeht of last several years ,the company has accomplished great achievements and achieved a high degree of credibility through untiring endeavor. Our sales areas mainly cover Europe,North America and South America ,Russia,Mid-East ,Asia etc.

We are looking forward to establishing business relationship with customers from all over the world for mutual development and a prosperous future.
Square Nuts for ANSI Inch SeriesSquare Nuts for ANSI Inch SeriesSquare Nuts for ANSI Inch SeriesSquare Nuts for ANSI Inch SeriesSquare Nuts for ANSI Inch Series
