Forged Turnbuckles Open Type for Construction

  • Carbon Steel

  • No

  • Common Bolt

Availability:

Product Description

Forged Turnbuckles, (Open Type)
DIN1480 size from M5-M56
Product Description


d
M6 M8 M10 M12 M16 M20 M24 M30 M36 M42 M48 M56
ds
e
f
L
L2
L1
h
12 15 18 21 27 34 39 45 55 63 80 80
12.90 15.9 18.9 21.9 27.9 35.1 40.1 46.2 56.2 64.3 81.5 81.5
11.50 14.5 17.5 20.5 26.5 33.5 38.5 44.4 54.4 62.3 79.3 79.3
19 23 30 34 42 52 60 74 86 104 135 135
19.9 23.9 30.9 35.1 43.1 53.1 61.1 75.2 87.2 105.3 136.7 136.7
18.5 22.5 29.5 33.5 41.5 51.5 59.5 73.4 85.4 103.3 134.3 134.3
9 11 14 16 20 24 28 34 40 50 65 65
9.5 11.5 14.5 16.5 20.5 24.5 28.5 34.6 40.6 50.7 65.7 65.7
8.1 10.1 13.1 15.1 19.1 23.1 27.1 32.8 38.8 48.7 63.5 63.5
110 110 125 125 170 200 255 255 295 330 355 355
111.1 111.1 126.2 126.2 171.3 201.3 256.3 256.3 296.7 332.1 357.1 357.1
109.5 109.5 124.4 124.4 169.3 199.3 254.3 254.3 294.2 328.9 353.9 353.9
12 15 18 21 27 34 39 45 55 63 78 78
6 8 9 11 14 17 20 23 28 32 39 39
6 8 9 11 14 17 20 23 28 32 40 40

Class: 4.8 8.8 10.9 12.9
Finishing: Black, Phosphate, Zinc, HDG, Dacromet, Geomet
Material: Q195, 35K, 45K, 40Cr, 35Crmo, 42Crmo, B7, SS304, SS316
Packing: Small box, Bulk, Euro-pallets, special label/box etc.

Lead time: 30-50 days.

In case you need more info pls contact us without hesitate.
Welcome send us inquiry!
Inquirires will be offered on same day or by the 2nd working day!
Company Profile


NINGBO MIANXUAN FASTENERS CO.,LTD. is a professional exporter specialized in fasteners products and located in Ningbo ,a beautiful city bordering on the East China Sea . The main products include various kinds of Bolts,Screws ,Nuts,Thread Rods,Stamping Parts that conform to the DIN,ISO, ANSI ,ASME ,BSW, J IS standards. The company also customizes non-standard items according to customer's requirements and specifications.

After a continuous creation and developmeht of last several years ,the company has accomplished great achievements and achieved a high degree of credibility through untiring endeavor. Our sales areas mainly cover Europe,North America and South America ,Russia,Mid-East ,Asia etc.

We are looking forward to establishing business relationship with customers from all over the world for mutual development and a prosperous future.
